Industrial Hydraulic Presses
HEMSUN ENGG. INDUSTRIES manufactures heavy-duty Industrial Hydraulic Presses across 4-pillar, H-frame, and C-frame configurations at our Dahegam (Gujarat) works. Explore standard models and custom builds below.
Working principle and engineering architecture
The hydraulic engineering behind Industrial Hydraulic Presses utilizes closed-loop proportional pressure and flow control, high-flow prefill valves for rapid approach, smooth micro-speed forming transitions, electronic decompression shock dampening, and bottom cushion/ejector cylinders for controlled draw and part ejection.
Variable-displacement axial piston pumps equipped with electronic proportional load-sensing match hydraulic output directly to the required tonnage and speed at each stage of the stroke. Regenerative rapid-advance circuits shorten cycle times by up to 40%, while stepped decompression manifolds eliminate hydraulic line shock and hydraulic water-hammer during full-force reversals. For deep-drawing lines, the bottom cushion cylinder features independently programmable blank-holding pressure curves to eliminate wrinkling and tearing in complex sheet geometries.
Types & Configurations We Build
Sizing and capacity calculations
Industrial Hydraulic Presses delivers rigid frame stability, smooth proportional hydraulic force delivery, and programmable stroke regulation for heavy industrial metalworking and component manufacturing. Built with stress-relieved steel plates and precision ground column guides, our hydraulic presses eliminate structural deflection under full rated tonnage across multi-shift production environments.
Sizing & Tonnage Calculations:
Hydraulic press capacity for forming and drawing operations is calculated from material yield strength, perimeter length, and sheet thickness:
Formula: Press Force (Ton) = (Forming Perimeter in mm × Thickness in mm × Shear Strength in N/mm² / 9810) × 1.25
Example: For a stainless steel deep-draw component with 600 mm draw perimeter and 2.5 mm thickness in SS-304 (Shear Strength = 450 N/mm²), required capacity is 86 Ton forming + 40 Ton cushion cylinder = 150 Ton Press.
Technical specifications and machine parameters
| Parameter / Specification | Standard Range / Feature |
|---|---|
| Press Classification | Industrial Hydraulic Presses (Industrial Hydraulic Series HSI) |
| Tonnage Capacity | 20 Ton to 1,000 Ton (Standard & Custom Tonnage Frames) |
| Frame Construction | Fabricated Welded H-Frame / 4-Pillar Ground Column Architecture |
| Platen Bolster Dimensions | 400 × 400 mm up to 2,000 × 2,000 mm Ground Steel |
| Stroke & Daylight Clearance | 150 mm to 1,200 mm Adjustable Stroke / Custom Daylight |
| Hydraulic Pumping Unit | Variable-Displacement Piston Pump with Proportional Load-Sensing |
| Manufacturing & Testing Origin | Manufactured, Assembled & Tested in Dahegam, Gandhinagar, Gujarat, India |
Material compatibility and engineering metallurgy
- Normalized IS:2062 Grade B Steel Plate: Ultrasonically tested heavy structural steel plates for ultra-rigid fabricated frames and bolsters.
- Hard Chrome Plated EN-8/EN-9 Piston Rods: Induction-hardened and ground rams with 30-micron hard chrome plating for leak-free seal longevity.
- Forged Cast Steel Cylinder Bodies: Seamless cylinder forgings honed to Ra ≤ 0.2 µm with multi-lip polyurethane and PTFE chevron seal packs.
- Phosphor Bronze Lined Guide Bushes: Precision column guide bushings with self-lubricating graphite plugs for frictionless vertical alignment.
Procurement and tooling selection guide
Key engineering considerations when selecting hydraulic presses:
- Frame Style: Choose 4-pillar ground columns for multi-directional access or welded H-frame box structures for high off-center load resistance.
- Hydraulic Drive: Variable-displacement axial piston pump with proportional load-sensing reduces power consumption by up to 50%.
- Cushion & Ejector Integration: Specify bottom hydraulic cushion cylinders with programmable blank-holder pressure profiles for deep drawing.
- Safety & Guarding: Ensure optical safety curtains, dual anti-tie-down buttons, and hydraulic mechanical ram lock-up systems.
Testing, inspection and global commissioning
HEMSUN ENGG. INDUSTRIES tests all industrial hydraulic presses with full-tonnage pressure dwell runs and platen deflection laser inspection. On-site installation, hydraulic oil charging, electrical connection, and trial part pressing are provided globally.
Frequently Asked Questions
What does HEMSUN list under Industrial Hydraulic Presses?
Browse Industrial Hydraulic Presses from HEMSUN, India — compression moulding machines, PTFE parts, hydraulic presses, tooling and custom OEM/ODM.
Can I request a quote from the Industrial Hydraulic Presses catalog page?
Yes. Use the contact page or RFQ buttons on detail pages. Include part drawing, size list, or machine tonnage target so our engineering team can respond with scope and lead time.
Does HEMSUN export products listed in Industrial Hydraulic Presses?
Yes. IEC-registered export documentation is available for qualified orders worldwide. Domestic buyers receive GST invoice and standard dispatch documentation.
